Printer Type | Inkjet | ||||
Print Head | Mono | Piezo with 210 nozzles x 1 | |||
Colour | ·       DCP-T520W/DCP-T525W
Piezo with 70 nozzles x 3 ·       DCP-T720DW/DCP-T725DW/DCP-T820DW/DCP-T825DW/MFC-T920DW/MFC-T925DW Piezo with 210 nozzles x 3 |
||||
Memory Capacity | 128 MB | ||||
Liquid Crystal Display (LCD) | ·       DCP-T520W/DCP-T525W/DCP-T720DW/DCP-T725DW/DCP-T820DW/DCP-T825DW
1 line LCD ·       MFC-T920DW/MFC-T925DW *1 1.8 in. (44.9 mm) TFT Colour LCD |
||||
Power Source | AC 100 to 120 V 50/60 Hz (Taiwan)
AC 220 to 240 V 50/60 Hz (Other countries) |
||||
Power Consumption *2 | ·       DCP-T520W/DCP-T525W (Taiwan)
Copying *3: Approx. 16 W Ready *5: Approx. 2.5 W Sleep *5: Approx. 0.8 W Power Off *5 *6: Approx. 0.2 W ·       DCP-T520W/DCP-T525W Copying *3: Approx. 16 W Ready *5: Approx. 3 W Sleep *5: Approx. 0.8 W Power Off *5 *6: Approx. 0.2 W ·       DCP-T720DW/DCP-T725DW Copying *4: Approx. 16 W Ready *5: Approx. 3 W Sleep *5: Approx. 0.8 W Power Off *5 *6: Approx. 0.2 W ·       DCP-T820DW/DCP-T825DW (Taiwan) Copying *4: Approx. 16 W Ready *5: Approx. 3 W Sleep *5: Approx. 0.9 W Power Off *5 *6: Approx. 0.2 W ·       DCP-T820DW/DCP-T825DW Copying *4: Approx. 17 W Ready *5: Approx. 3 W Sleep *5: Approx. 0.9 W Power Off *5 *6: Approx. 0.2 W ·       MFC-T920DW/MFC-T925DW (Taiwan) Copying *4: Approx. 19 W Ready *5: Approx. 3.5 W Sleep *5: Approx. 1.2 W Power Off *5 *6: Approx. 0.2 W ·       MFC-T920DW/MFC-T925DW Copying *4: Approx. 17 W Ready *5: Approx. 4 W Sleep *5: Approx. 1.2 W |
||||
Weights | ·       DCP-T520W/DCP-T525W (Taiwan)
7.2 kg ·       DCP-T520W/DCP-T525W 7.3 kg ·       DCP-T720DW/DCP-T725DW(Taiwan) 8.6 kg ·       DCP-T720DW/DCP-T725DW 8.7 kg ·       DCP-T820DW/DCP-T825DW (Taiwan) 9.5 kg ·       DCP-T820DW/DCP-T825DW 9.6 kg ·       MFC-T920DW/MFC-T925DW (Taiwan) 9.6 kg ·       MFC-T920DW/MFC-T925DW 9.7 kg |
||||
Noise Level | Sound Pressure | Operating | 53.5 dB (A) (Approx.)Â *7 | ||
Temperature | Operating | 10 to 35°C | |||
Best Print Quality | 20 to 33°C | ||||
Humidity | Operating | 20 to 80% (without condensation) | |||
Best Print Quality | 20 to 80% (without condensation) | ||||
Automatic Document Feeder (ADF)
(DCP-T720DW/DCP-T725DW/DCP-T820DW/DCP-T825DW/MFC-T920DW/MFC-T925DW) |
Up to 20 pages
Paper: 80 gsm |
||||
Document Size Specifications
Document Size | ADF Width
(DCP-T720DW/DCP-T725DW/DCP-T820DW/DCP-T825DW/MFC-T920DW/MFC-T925DW) |
148 to 215.9 mm |
ADF Length *1
(DCP-T720DW/DCP-T725DW/DCP-T820DW/DCP-T825DW/MFC-T920DW/MFC-T925DW) |
148 to 355.6 mm | |
Scanner Glass Width | Max. 215.9 mm | |
Scanner Glass Length | Max. 297 mm |
Fax Specifications
Compatibility | ITU-T Group 3 |
Modem Speed | Automatic Fallback: 14,400 bps |
Scanning Width
(Single-sided document) |
ADF: 208 mm (A4)
Scanner Glass: 204 mm (A4) |
Printing Width | 204 mm (A4) |
Resolution
(Horizontal) |
203 dpi |
Resolution
(Vertical) |
Standard:
98 dpi (Mono) |
Fine:
196 dpi (Mono) |
|
Superfine:
392 dpi (Mono) |
|
Photo:
196 dpi (Mono) |
|
Address Book | 40 numbers (MFC-T920DW/MFC-T925DW) |
Groups | Up to 6 |
Broadcasting | 90 (40 Address Book/50 Manual Dial)Â (MFC-T920DW/MFC-T925DW) |
Automatic Redial | 3 times at 5 minute intervals |
Memory Transmission | Up to 170 pages (MFC-T920DW/MFC-T925DW) *1 |
Out of Paper Reception | Up to 170 pages (MFC-T920DW/MFC-T925DW) *1 |
Copy Specifications
Colour/Monochrome | Yes/Yes |
Copy Width | 204 mm *1 |
Multiple Copies | Stacks/Sorts up to 99 pages |
Enlarge/Reduce | 25% to 400% (in increments of 1%) |
Resolution | Prints up to 1200 × 1800 dpi (DCP-T520W/DCP-T525W)
Prints up to 1200 × 2400 dpi (DCP-T720DW/DCP-T725DW/DCP-T820DW/DCP-T825DW/MFC-T920DW/MFC-T925DW) |
PhotoCapture Center Specifications
Compatible Media *1 | USB Flash drive *2 | |
Photo | Resolution | Up to 1200 x 6000 dpi (MFC-T920DW/MFC-T925DW) |
Paper Type | Plain Paper, Inkjet Paper (coated paper), Glossy Paper, Brother BP71 paper | |
Paper Size | A4, Letter, Photo (10 x 15 cm), Photo 2L (13 x 18 cm) | |
File Format | JPEG (Progressive JPEG format is not supported) | |
Scan to Media | File Format | JPEG, PDF (Colour, Grey)
TIFF, PDF (Monochrome) |
Scanner Specifications
Colour/Monochrome | Yes/Yes |
TWAIN Compliant | Yes
(Windows 7 SP1 / Windows 8.1 / Windows 10 / Windows 11) |
WIA Compliant | Yes
(Windows 7 SP1 / Windows 8.1 / Windows 10 / Windows 11) |
Colour Depth | 30 bit colour processing (Input)
24 bit colour processing (Output) |
Greyscale | 10 bit colour processing (Input)
8 bit colour processing (Output) |
Resolution | Up to 19200 × 19200 dpi (interpolated) *1 *2
(from Scanner Glass) Up to 1200 × 2400 dpi (optical) (from ADF) *3 Up to 1200 × 600 dpi (optical) |
Scanning Width and Length
(Single-sided document) |
(Scanner Glass)
Width: Up to 213.9 mm Length: Up to 295 mm (ADF)Â *3 Width: Up to 213.9 mm Length: Up to 353.6 mm |
Interface Specifications
USBÂ *1Â *2 | Use a USB 2.0 interface cable that is no longer than 2 m. |
LAN
(DCP-T820DW/DCP-T825DW/MFC-T920DW/MFC-T925DW) |
Use an Ethernet UTP cable category 5 or greater. |
Wireless LAN | IEEE 802.11b/g/n (Infrastructure)
IEEE 802.11g/n (Wi-Fi Direct) |
Network Specifications
Network Security (Wired)
(DCP-T820DW/DCP-T825DW/MFC-T920DW/MFC-T925DW) |
SSL/TLS (IPPS, HTTPS) | |
Network Security (Wireless) | SSL/TLS (IPPS, HTTPS) | |
Wireless Network Security | SSID (32 characters), WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES) | |
Wireless Setup Support Utility | WPS | Yes |
