Operating Systems Compatibility‡ | Compatible with Windows, Mac® and Linux. Visit support.brother.com for the latest OS compatibility and to download your machine’s drivers and software. |
Standard Interface(s) | SuperSpeed USB 3.0 (USB 2.0 compatible) |
USB Host Location(s) | Back: Scan to USB Memory Stick |
Dimensions
Carton Dimensions (W” x D” x H”) | 9.500 ” x 15.500 ” x 12.250 “ |
Carton Weight (lbs) | 1.124 |
Unit Dimensions (W” x D” x H”) | 11.7″ x 8.5″ x 7.5″ |
Unit Weight (lbs) | 9.81 |
Document Handling
Automatic Document Feeder Capacity (max. pages)‡ | 60 |
Daily Duty Cycle (max. pages)‡ | 6000 |
Media Types | Plain, Receipts (carrier sheet recommended), Photos (carrier sheet required), Business Cards, Plastic/Laminated Cards (including embossed), Bond, Recycled Paper |
Media Weights: (min/max) | 11 – 53 lbs. |
Paper Size (min) | 2.0″(W) – 2.0″ (L) |
Paper Size: Single Sheet‡ (max.) | 8.5″ (W) – 197″ (L) |
Plastic Card Sizes (Min/Max) | 2.13″ (W) x 3.37″ (L) |
Plastic Card Thickness | Embossed: Up to 1.32mm (0.05″) Without Embossing: Up to 1.10mm (0.04″) |
Power
Auto Power Off | Yes |
ENERGY STAR® Certified | Yes |
EPEAT® Registered | Silver |
Operating Environment: Humidity | Operating 20% / 80%, Storage 10% / 90% |
Operating Environment: Temperature | 41°F – 95°F (5°C – 35°41°F – 95°F (5°C – 35°C)C) |
Power Consumption – Power Off/Ready/Scanning/Sleep | 0.1W, 5.4W, 23W, 1.4W |
Power Source | AC Adapter |
Scan
Advanced Scanning Features | Continuous Scan, Barcode Metadata, 1 to 2 Scan, 2 to 1 Scan, Color Drop Out, Hole Punch Removal, Background Color Removal, Auto Image Rotation, Auto Scan Size, Bleed-through Removal, Auto Color Detection , ADF Auto Deskew, Blank Page Skip |
Barcode Types Supported | UPC-A, UPC-E, JAN8, JAN13, Code39, Code93, ITF, Code128, Codabar, GS1_128, PDF417, QR Code, Data Matrix |
Cloud Services‡ | Google Drive™/Google Drive for Business, OneDrive/OneDrive for Business, Dropbox/Dropbox for Business |
Duplex Scan Speeds (black & color) (max ipm)‡ | 80 |
Duplex Scanning | Yes |
Included Software‡ | Kofax Power PDF for Windows, Presto! BizCard for Windows and Mac®, Brother iPrint&Scan (desktop) for Windows and Mac®, Brother ScanEssentials Lite for Windows, Image Folio Processing Software for Windows, Kofax PaperPort™ SE with OCR for Windows |
Interpolated Scan Resolution (max. dpi) | Up to 1200 x 1200 dpi |
Optical Scan Resolution (max. dpi) | 600 x 600 dpi |
Scan Driver OS Compatibility‡ | Windows, Mac OS®, Linux |
Scan Drivers Included‡ | TWAIN, WIA, ICA, ISIS, SANE |
Scan File Formats | PDF Single-page/Multi-page (Secure PDF, Searchable PDF, PDF/A), Microsoft Office Excel (XLSX), Windows Bitmap (BMP), Microsoft Office Word (DOCX), JPEG (JPG), PDF Single-page/Multi-page (PDF/A, High Compression PDF, Microsoft Office PowerPoint (PPTX), TIFF Single-page/Multi-page (TIF), Text (TXT), Microsoft Excel 2003 XP (XLS) |
Scanner Type | Sheetfed |
Scanning Capability | Black and White, Color |
Scanning Modes | 24-Bit Color, 8-Bit Gray Scale, 1-Bit Monochrome |
Simplex Scan Speeds (black & color) (max ppm)‡ | 40 |
Security Features
Security Functions | Lock Slot |
What’s Included
Carton Contents | Brother ADS-3100, USB 3.0 Interface Cable, AC Adapter, Quick Setup Guide |
