INPUT | ||||||||||||
Nominal voltage | 208/220/230/240Vac | |||||||||||
Input voltage range | 110~300Vac (176~280Vac @ 100% load) | |||||||||||
Frequency range | 40~70Hz  (50/60Hz Auto-Sensing) | |||||||||||
Power factor | ≥0.99 | |||||||||||
OUTPUT | ||||||||||||
Output voltage | 208/220/230/240Vac | |||||||||||
Power factor | 0.9 | |||||||||||
Voltage regulation | ±1% | |||||||||||
Output frequency | Line Mode | 46~54Hz or 56~64Hz | ||||||||||
Bat. Mode | (50/60±0.1%)Hz | |||||||||||
Crest factor | 3:01 | |||||||||||
Harmonic distortion (THDv) | ≤3% Linear load | |||||||||||
≤5% Non linear load | ||||||||||||
Transfer time | AC mode to Bat.Mode | 0ms | ||||||||||
Inverter to Bypass | 4ms (Typical) | |||||||||||
Output waveform | Pure Sinewave | |||||||||||
EFFICIENCY | ||||||||||||
AC mode | 89% | 91% | 92% | |||||||||
Battery mode | 85% | 87% | 88% | |||||||||
BATTERY | ||||||||||||
Battery number | 2 | 3 | 2 | 3 | 4 | 6 | 4 | 6 | 6 | 8 | 6 | |
Capacity (Standard unit) | 9Ah/12V | |||||||||||
Typical recharging time | 4 hours (to 90% of full capacity) | |||||||||||
Charging voltage | 27.4Vdc±1% | 41.1Vdc±1% | 27.4Vdc±1% | 41.1Vdc±1% | 54.8Vdc±1% | 82.2Vdc±1% | 54.8Vdc±1% | 82.2Vdc±1% | 82.2Vdc±1% | 109.6Vdc±1% | 82.2Vdc±1% | |
Charging current (Max) | 6A/12A | 1A | 6A/12A | 1A | 6A/12A | 1A | ||||||
INDICATORS | ||||||||||||
LED display | Line mode,Bat.mode,ECO mode,Bypass mode,Battery low voltage,Overload & UPS fault | |||||||||||
LCD display | Input voltage,Input frequency,Output voltage,Output frequency,Load percentage, | |||||||||||
Battery voltage,Inner temperature& Remaining battery backup time | ||||||||||||
ALARM | ||||||||||||
Battery mode | Beeping every 4 seconds | |||||||||||
Battery low | Beeping every second | |||||||||||
Overload | Beeping twice every second | |||||||||||
Fault | Continously beeping | |||||||||||
PHYSICAL | ||||||||||||
Dimension W x D×H (mm) | 440 x 325x 86.5 | 440 x 460 x 86.5 | 440 x 600 x 86.5 | 440 x 460 x 86.5 | 440 x 600 x 86.5 | |||||||
Net weight (kg) | 5.6 | 11.3 | 14 | 10.5 | 19.5 | 25 | 11 | 26 | ||||
ENVIRONMENT | ||||||||||||
Operating temperature | 0℃~40℃ | |||||||||||
Storage temperature | -25℃~55℃ | |||||||||||
Humidity range | 20~95%RH @ 0~40℃ (Non condensing) | |||||||||||
Altitude | <1500m,derating required when>1500m | |||||||||||
Noise level | <50db at 1 Meter | |||||||||||
STANDARDS | ||||||||||||
Safety | IEC/EN62040-1,IEC/EN62477-1 |
