QNAP TS-431KX-2G 4-Bay NAS Enclosure

QAR 3,083

Availability:

Available on backorder

Delivery within 3 - 4 weeks.( Delivery time may change depending on the stock)
  • 4 x 3.5″ / 2.5″ SATA III Drive Bays
  • 1.7 GHz Annapurna Labs AL214 Quad-Core
  • 2GB DDR3 RAM
  • 2 x RJ45 Gigabit Ethernet Ports
  • 1 x 10Gb SFP+ Port
  • 3 x USB 3.1 Gen 1 Ports
  • RAID 0, 1, 5, 6, 10, JBOD, Single
  • Up to 1117 MB/s Sequential Read Speeds
  • Up to 511 MB/s Sequential Write Speeds
  • QTS 5.0.0
  • 4 x 3.5″ / 2.5″ SATA III Drive Bays
  • 1.7 GHz Annapurna Labs AL214 Quad-Core
  • 2GB DDR3 RAM
  • 2 x RJ45 Gigabit Ethernet Ports
  • 1 x 10Gb SFP+ Port
  • 3 x USB 3.1 Gen 1 Ports
  • RAID 0, 1, 5, 6, 10, JBOD, Single
  • Up to 1117 MB/s Sequential Read Speeds
  • Up to 511 MB/s Sequential Write Speeds
  • QTS 5.0.0

QAR 3,083

Available on backorder

Order By Call

Order now & Get it delivered Today!!

Computing

CPU 1.7 GHz Quad-Core
Processor Annapurna Labs Alpine AL214
Total Installed Memory 2 GB DDR3
User-Replaceable Memory 1 x 2 GB
Total Memory Slots 1 x SO-DIMM
Maximum Memory Capacity 8 GB
Flash Memory 512 MB

General

Number of Bays 4 x 2.5″/3.5″
I/O 2 x RJ45 (Gigabit Ethernet)
1 x SFP+ (10GbE)
3 x USB Type-A (USB 3.1 / USB 3.2 Gen 1 (5 Gb/s))
Compatible Drive Interface SATA II, SATA III
Media Card Slots None
Form Factor Desktop
RAID RAID 0, 1, 10, 5, 6, JBOD, Single
Hot-Swap Support Yes
Wake on LAN Yes

Networking

Supported Protocols AFP
CIFS/SMB
FTP
IPv4
IPv6
L2TP/IPSec
OpenVPN
PPTP
iSCSI
iSCSI LUN 256
iSCSI Target 256
Max Concurrent Connections 400
Max Folders 512
Max Groups 512
Max User Accounts 4096
Max Volume Number 128
Max Cameras Supported 3000

Software

Installed Operating System QTS 5.0.0
Supported File Systems Internal: EXT4
External: EXT3, EXT4, FAT32, HFS+, NTFS, exFAT
OS Compatibility macOS 10.10 or Later
Windows 7 or Later
Windows Server 2008 R2 or Later
Ubuntu 14.4 or Later
CentOS 7 or Later
Linux
UNIX
*As of December, 2021: check with manufacturer for the most up-to-date compatibility
Supported Browsers Chrome, Edge, Firefox, Safari

Security

Encryption 256-Bit AES
Security Features Lockable Bay Door
VPN Client Connections 100

Electrical

AC Input Power 100 to 240 VAC, 50 / 60 Hz
Power Source AC Adapter
Power Consumption 26.7 W (Typical)
11.65 W (Idle)

Environmental

Operating Temperature 32 to 104°F / 0 to 40°C
Operating Humidity 5 to 95%
Storage Temperature -4 to 158°F / -20 to 70°C

Physical

Status Monitoring LED Indicator
Audible Alarm Yes
Cooling 1 x 120 mm Fan
Noise Level 19.5 dBA
Built-In Speakers None
IR Sensor None
Dimensions 8.6 x 6.6 x 6.3″ / 21.95 x 16.54 x 16 cm
Weight 4.4 lb / 2.0 kg

Enhance your home or small business network’s storage capacity for fast backups, data sharing, surveillance, and more with the QNAP TS-431KX-2G 4-Bay NAS Enclosure. Powered by a 1.7 GHz Annapurna Labs AL214 quad-core processor with 2GB of DDR3 memory, this entry-level network attached storage (NAS) enclosure features four hot-swappable 3.5″ / 2.5″ SATA III drive bays with support for RAID 0, 1, 5, 6, 10, JBOD, and Single configurations. It integrates into your network through its dual RJ45 Gigabit Ethernet ports or its 10Gb SFP+ fiber connector. When configured in four SATA III solid-state drives in RAID 5 mode, the TS-431KX-2G can deliver sequential read speeds of up to 1117 MB/s and 511 MB/s sequential write speeds over the 10GbE connection. With support for Hybrid Backup Sync, snapshots, and 256-bit AES hardware encryption, your data is protected from potential threats and other issues. The TS-431KX-2G uses the QTS 5.0.0 operating system.

Fast Connection
Connecting the high-speed 10Gb SFP+ port to a compatible device helps you to spend less time waiting for large data transfers and backups to complete.

Hybrid Backup Sync
Hybrid Backup Sync (HBS) technology provides comprehensive disaster recovery by automatically backing up and syncing your data across multiple NAS devices, servers, and cloud storage services.

Snapshots
Use snapshots to fully record your system status and data to protect against accidental deletion, malware attacks, and more. QNAP snapshots are block-based and only record modified data, which helps to conserve storage space while reducing backup and recovery times.

Hot-Swapping
Hot-swapping support provides continuous operation by allowing you to remove and replace drives without having to power down the NAS.

Virtual JBOD
With Virtual JBOD (VJBOD) technology, you can quickly expand your storage space by connecting additional NAS systems.

USB 3.1 Gen 1
Three USB 3.1 Gen 1 Type-A ports are available for transferring up to 5 Gb/s with compatible peripherals such as keyboards, mice, webcams, and external storage drives.

Surveillance Solution
The TS-431KX-2G supports over 3000 IP cameras across 16 expandable channels. Two free IP camera channels are included, and the system supports both IP cameras and USB webcams.

QTS OS
The QTS 5.0.0 operating system supports a variety of apps to help back up, organize, and share data across your network.
