Teltonika TSW100 Industrial Rugged Unmanaged PoE+ Switch

QAR 349

Availability:

In stock

SKU : TSW100000000 • MFR SKU : TSW100

  • TSW100 is the first industrial unmanaged switch from Teltonika Networks.
  • Equipped with five Gigabit Ethernet ports, four of which support IEEE802.3af and IEEE802.3at Power-over-Ethernet standards (PoE).
  • Classified as power source equipment (PSE), it enables centralization of the power supply, providing up to 30 watts per port and reducing the effort for installing power.
  • It has 10/100/1000 Mbps Ethernet ports for an economical high-bandwidth solution.
  • Ideal for professional high bandwidth applications to provide both: reliable data connection and power supply.
  • TSW100 is the first industrial unmanaged switch from Teltonika Networks.
  • Equipped with five Gigabit Ethernet ports, four of which support IEEE802.3af and IEEE802.3at Power-over-Ethernet standards (PoE).
  • Classified as power source equipment (PSE), it enables centralization of the power supply, providing up to 30 watts per port and reducing the effort for installing power.
  • It has 10/100/1000 Mbps Ethernet ports for an economical high-bandwidth solution.
  • Ideal for professional high bandwidth applications to provide both: reliable data connection and power supply.

QAR 349

In stock

Order By Call
ETHERNET
LAN 5 x LAN port, 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover
POE
PoE ports Port 1- 4
PoE standards 802.3af and 802.3at
PoE Max Power per Port (at PSE) 30 W
Total PoE Power Budget (at PSE) 120 W
PERFORMANCE SPECIFICATIONS
Bandwidth (Non-blocking) 10 Gbps
Packet buffer 128 KB
Jumbo frame support 9216 bytes
MAC address table size 2K entries
POWER
Connector 4 pin industrial DC power socket
Input voltage range 7-58 VDC
Power consumption (idle/max no PoE/max) 2 W/9 W/129 W
PHYSICAL INTERFACES (PORTS, LEDS)
Ethernet 5 x RJ45 ports, 10/100/1000 Mbps
Status LED’s 1 x Power LED, 10 x LAN status LED’s
Power 1 x 4 pin DC connector
Ground 1 x Grounding screw
PHYSICAL SPECIFICATION
Casing material Full aluminum housing
Dimensions 95 x 115 x 32 mm (L x W x H)
Mounting DIN rail or wall mounting (additional kit needed), flat surface placement
OPERATING ENVIRONMENT
Operating temperature -40 °C to +75 °C
Operating humidity 10 % to 90 % non condensing

TSW100 is the first industrial unmanaged switch from Teltonika Networks.Equipped with five Gigabit Ethernet ports, four of which support IEEE802.3af and IEEE802.3at Power-over-Ethernet standards (PoE).Classified as power source equipment (PSE), it enables centralization of the power supply, providing up to 30 watts per port and reducing the effort for installing power.It has 10/100/1000 Mbps Ethernet ports for an economical high-bandwidth solution.Ideal for professional high bandwidth applications to provide both: reliable data connection and power supply.

POE
4 x PoE ports with 802.3af and 802.3at support

DURABILITY
Rugged aluminium housing

MOUNTING
DIN rail and surface mounting options

POWER BUDGET
Total power budget at PSE up to 120 W

ETHERNET
5 x Gigabit Ethernet with speeds up to 1000 Mbps

PLUG-N-PLAY
No additional configuration needed
