IEEE 802.11ac/n/a 5 GHz
IEEE 802.11n/b/g 2.4 GHz
5 GHz: 1300 Mbps (802.11ac)
2.4 GHz: 600 Mbps (802.11n)
|WiFi Range||3 Bedroom Houses
4× Fixed High-Performance Antennas
|Working Modes||Router Mode
Access Point Mode
|Processor||1.2 GHz CPU|
|Ethernet Ports||1× Gigabit WAN Port
4× Gigabit LAN Ports
Power On/Off Button
12 V ⎓ 1.5 A
|Network Security||SPI Firewall
IP & MAC Binding
Application Layer Gateway
|Guest Network||1× 5 GHz Guest Network
1× 2.4 GHz Guest Network
|Parental Controls||URL Filtering
|WAN Types||Dynamic IP
|Quality of Service||QoS by Device|
|Cloud Service||OTA Firmware Upgrade
|NAT Forwarding||Port Forwarding
DHCP Client List
|Dimensions (W×D×H)||8.5 × 4.6 × 1.26 in
(215 × 117 × 32 mm)
|Package Contents||Wi-Fi Router Archer C80
RJ45 Ethernet Cable
Quick Installation Guide
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access)
|Environment||Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
|WiFi Transmission Power||FCC:
<30dBm(2.4GHz & 5GHz)
|WiFi Reception Sensitivity||5GHz:
11a 6Mbps:-98dBm, 11a 54Mbps:-78dBm
11ac VHT20_MCS0:-98dBm, 11ac VHT20_MCS8:-72dBm
11ac VHT40_MCS0:-92dBm, 11ac VHT40_MCS9:-68dBm
11ac VHT80_MCS0:-89dBm, 11ac VHT80_MCS9:-64dBm2.4GHz:
11g 6Mbps:-97dBm, 11a 54Mbps:-77dBm
11n VHT20_MCS0:-97dBm, 11n VHT20_MCS8:-72dBm
11n VHT40_MCS0:-92dBm, 11n VHT40_MCS9:-67dBm
Maximum WiFi Performance with Three Streams
With 3×3 MIMO, Archer C80 is capable of transmitting and receiving data on three streams. 3×3 capable computers— like Macs—pair perfectly with C80 to perform at max with much higher efficiency than 2×2 MIMO routers.
Incredible 802.11ac Wave2 Series WiFi
The affordable Archer C80 delivers high-performance WiFi with total speeds up to 1900 Mbps. Handle simple tasks like sending e-mails or web browsing on the 2.4 GHz band and bandwidth-intensive tasks like online gaming or 4K/8K UHD streaming on the 5 GHz band—all lag-free.
Broader Coverage Throughout Your Home
Access your entertainment from every corner of your home with 4 external high-performance antennas. Beamforming technology detects devices and concentrates wireless signal strength towards them, even if they are far away or low-powered.
Connect More Devices Simultaneously
Archer C80 helps your devices achieve optimal performance by making communication more efficient with MU-MIMO technology. MU-MIMO allows multiple devices to send and receive data simultaneously. Enjoy non-stop entertainment on all your devices.
Increased Efficiency in WiFi Distribution
Smart Connect helps your router automatically switch each device’s connection to the best available WiFi band while Airtime Fairness prevents older devices from slowing down your network. With both, everyone can enjoy a smoother, buffer-free WiFi experience.
Full Gigabit Ports
Gigabit Ethernet ports (1 WAN+ 4 LAN) deliver maximum wired speeds. Plug in your PCs, smart TVs, and game consoles for fast and reliable connections.
Personalize Your Home Network
Archer C80 provides a wealth of advanced tools for personalized management.
Easy Setup at Your Fingertips
Set up Archer C80 in minutes via its intuitive web interface or the powerful Tether app. Tether also lets you manage its network settings from any Android or iOS device.
