POWER | |
AC adapter input | 100-240V ~ 50/60Hz 0.4A |
AC adapter output | 12V ⎓ 1.2A |
HARDWARE FEATURES | |
Processor | Qualcomm CPU |
Interface | 2 Gigabit Ethernet Ports (WAN/LAN auto-sensing) per Deco unit |
Button | 1 Reset button on the underside |
External Power Supply | 12 V/1.2 A |
Dimensions | Φ3.6 in. x 7.5 in. (Φ90.7 mm x 190 mm) |
Antenna Type | 2 internal dual-band antennas per Deco unit |
WIRELESS FEATURES | |
Wireless Standards | IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2.4 GHz |
Frequency | 2.4 GHz and 5 GHz |
Signal Rate | 300 Mbps on 2.4 GHz 867 Mbps on 5 GHz |
Transmit Power | FCC: <30 dBm CE: <20 dBm (2.4 GHz) <23 dBm (5 GHz) |
Wireless Security | WPA-PSK/WPA2-PSK |
Advanced Functions | ● Router/ Access Point Mode ● Optional Ethernet Backhaul ● Guest network ● TP-Link Mesh Technology: MU-MIMO Auto Path Selection Self-Healing AP Steering Band Steering Beamforming |
SOFTWARE FEATURES | |
Quality of Service | WMM |
IPv6 | Support |
WAN Type | Dynamic IP/Static IP/PPPoE/L2TP/PPTP |
Management | Local Management, Remote Management |
DHCP | Server, Client |
Port Forwarding | Support |
Access Control | Blacklist |
Firewall Security | SPI Firewall |
Protocols | Supports IPv4 and IPv6 |
Advanced Features | Parental Controls Quality of Service |
Advanced Functions | Monthly Reports Auto FW Update Expand Wi-Fi by adding more Deco units |
Guest Network | 2.4 GHz guest network x 1 5 GHz guest network x 1 |
Beamforming | Support |
APP | Easy setup via Deco App |
OTHERS | |
Certification | CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC, RoHS |
Package Contents | ● Deco M4 (3-pack): 3 Deco units 1 RJ45 Ethernet Cable 3 power adapters 1 quick installation guide ● Deco M4 (2-pack): 2 Deco units 1 RJ45 Ethernet Cable 2 power adapters 1 quick installation guide ● Deco M4 (1-pack): 1 Deco unit 1 RJ45 Ethernet Cable 1 power adapter 1 quick installation guide |
Smartphone/Tablet Requirements | iOS 9.0 or later, Android 4.4 or later |
Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
Experience Wi-Fi Like Never Before
Deco M4 uses TP-Link Mesh technology to cover your entire home in powerful Wi-Fi. Multiple units seamlessly work together to create a home network like nothing you’ve ever experienced.
Wi-Fi Dead-Zone Killer
Deco M4 is the simplest way to guarantee a strong Wi-Fi signal in every corner of your home up to 4,000 square feet (3-pack, EU version)†. Wireless connections and optional Ethernet backhaul work together to link Deco units, providing even faster network speeds and truly seamless coverage.
Want more coverage? Simply add another Deco.
Seamless Roaming with One Wi-Fi Name
TP-Link Mesh means Deco units work together to form one unified network. Your phone or tablet automatically connects to the fastest Deco as you move through your home, creating a truly seamless Wi-Fi experience‡.
No More Buffering
Network speeds three times faster than previous generation routers, thanks to 802.11ac wireless technology, make Deco capable of providing a lag-free connection to up to 100 devices
2-in-1 Router and Access Point Modes
Flexible and multifunctional, the Deco M4 includes a variety of features allowing it to serve as a router or access point. Just choose the mode for your actual network demands and experience the maximum wireless flexibility.
App-Based Setup
Installing Deco M4 is fast and easy. Just unpack the system, download the Deco app and follow its onscreen directions.- Easy Management
Manage your Wi-Fi at home or away in the Deco app, including seeing the connected devices, prioritizing your devices, setting up a guest network and more. - Voice Control
Pair with Alexa to control Deco M4 with simple voice commands. Enjoy the convenient life.
Robust Parental Controls
Simple, intuitive parental controls make it easy to keep your children safe while they’re online.
All Decos Work Together
Deco M4 is compatible with every other Deco model to form a Mesh network. Expand Mesh Wi-Fi coverage anytime by simply adding more Decos
