Yamaha T-S500 AM/FM Stereo Tuner

QAR 799

Availability:

Available on backorder

Delivery time depends on availability of the item with supplier.
SKU: T-S500-BLK
MFR SKU: T-S500-BLK
Categories: , , ,

  • 40-Station AM/FM Preset Tuning
  • Auto FM Station Memory
  • Multi-Status Station Memory
  • 2-Line, 16-Character Display
  • 40-Station AM/FM Preset Tuning
  • Auto FM Station Memory
  • Multi-Status Station Memory
  • 2-Line, 16-Character Display

QAR 799

Available on backorder

Order By Call

Order now & Get it delivered Today!!

Tuning Range 87.5 to 107.9 MHz
Output Level and Impedance 40 kHz Dev., 1 kHz: 1.0 V / 1.2 Kilohms
50dB Quieting Sensitivity Mono: 3 μV (20.2 dBf)
Usable Sensitivity SNR: 30 dB Mono: 1 μV
Image Rejection Ratio: 80 dB
IF Rejection Ratio: 70 dB
Selectivity (400 kHz): 70 dB
Signal to Noise Ratio Mono: 80 dB
Stereo: 75 dB
Harmonic Distortion Mono: 0.3%, 1 kHz
Stereo: 0.5%, 1 kHz
Stereo Separation 40 kHz Dev., 1 kHz: 43 dB
Frequency Response (-3 dB) 20 Hz to 15 kHz
Antenna Input Unbalanced, 75 Ohms
Tuning Range 530 to 1710 kHz
Output Level and Impedance 30% Mod., 1 kHz: 0.36 V / 1.2 Kilohms
Usable Sensitivity 300 μV/m
Selectivity 30 dB
Signal to Noise Ratio 50 dB
Image Rejection 35 dB
Harmonic Distortion 1.0 %
Output 1 x Stereo RCA
Presets 40
Power Requirements 120 VAC, 60 Hz
Power Consumption 9 W
Dimensions 17.1 x 3.4 x 12″ / 43.5 x 8.7 x 30.6 cm
Weight 7.1 lb / 3.2 kg

The Yamaha T-S500 AM/FM Stereo Tuner connects to your external amplifier and speaker system to give you access to your favorite AM and FM radio stations. To that end, it features memory for 40 presets, which can all be accessed via two turns of the rotary encoder knob or with the remote control from your Yamaha amplifier or receiver. Favorite stations can be set at either end for greater convenience.

40-Station AM/FM Preset Tuning
All 40 stations can be accessed with two turns of the rotary encoder knob, after which it stops. Favorite stations can be set at either end for greater convenience.
Auto FM Station Memory
Automatically presets the 40 strongest FM stations on the dial so you don’t have to select and preset them manually.
Multi-Status Station Memory
Thanks to multi-status station memory, each station memory includes the parameters set when it was memorized, for optimum quality each time it is selected.
2-Line, 16-Character (5 x 7 Dot Matrix) Display
This high and wide display offers better visibility than previous types (1-line, 11-character displays). It provides a larger amount of more precise information, making the tuning operation easier.
IR Sensor on Front Panel
Allows the remote control from Yamaha Integrated Amplifiers (including the A-S500) to control the tuner.
