|Total power||700 W|
|AC input voltage||230 V|
|Power Factor Correction type||Active|
|Motherboard power connection||20 + 4 pin ATX|
|Peripheral (Molex) power connections (4-pin)||3|
|Number of SATA power connections||6|
|PCI Express speed connector (6 + 2 pins)||2nd|
|CPU P4 connector (4 pins)||one|
|CPU power connector (4 + 4 pins)||Yes|
|Power supply unit (PSU) form factor||ATX|
|80 PLUS certification||80 PLUS|
|Certificates, compliance statements||CE, FCC, TUV|
|Type of cooling||Active|
|Fan diameter||12 cm|
|Number of fans||1 fan (s)|
|Integrated on / off button||Yes|
|Weight & dimensions||Width140 mm, Depth150 mm, Height86 mm|
80 PLUS® Efficiency
With the STX700, the computer’s power supply efficiency will reach the highest level. Moreover, at a very reasonable cost.
Fine Tuning Fan Speed
The COUGAR STX700 fan automatically adjusts its speed according to the PSU temperature. This feature will ensure that the fan noise is minimized in any case.
120mm Ultra Quiet Fan
Ultra quiet & Temperature controlled 120mm fan. Provides better power output with its thermal control.
With its extremely low noise level, the fan speed is automatically regulated according to the temperature.
High efficiency up to 88%.
Multi-GPU technology Support
Supports PCI Express 3.0 new generation graphics cards with 8 (6 + 2) pin PCI-E connector.
Integrated Air Intake Design
Provides quieter operation with optimal aerodynamic design.
Compliant with the latest EU regulation
Energy consumption during standby <0.5W.
Compatible with the latest PC technology
Created for use with existing and new generation multi-core CPU platforms.
Ultra quiet & Temperature controlled 120mm fan
Extremely low noise level. Fan speed is regulated automatically according to its temperature.
Active Power Factor Correction (Active PFC)
It provides clean and reliable energy up to 99% PF value.
