Panel Technology | IPS TFT with W-LED backlight |
Screen Size [inch/cm] | 23 / 58 |
Screen Aspect Ratio | 16:9 |
Pixel Pitch [mm] | 0.265 |
Brightness (typ.) [cd/m²] | 250 |
Contrast Ratio (typ.) | 1000:1 (25000:1 dynamic contrast ratio) |
Viewing Angle [°] | 170 horizontal / 160 vertical (typ. at contrast ratio 10:1); 176 horizontal / 170 vertical (typ. at contrast ratio 5:1) |
Response Time (typ.) [ms] | 6 (grey-to-grey) |
Colours [Mio.] | 16.7 |
Horizontal Frequency [kHz] | 31.5 – 81.1 |
Vertical Frequency [Hz] | 56 – 76 |
Optimum Resolution | 1920 x 1080 at 60 Hz |
Digital | 1 x DisplayPort; 1 x DVI-D |
Analog | 1 x mini D-sub 15 pin |
Power Consumption on Mode [W] | 19 (Eco Mode); 24 (typ.) |
Power Savings Mode [W] | < 0.35 |
Power Supply | 0.6 A/0.35 A; 100-120 V/220-240 V; integrated power supply |
Operating Temperature [°C] | +5 to +35 |
Operating Humidity [%] | 20 to 80 |
Height adjustable Stand [mm] | 110 |
Screen Tilt / Swivel / Rotate [°] | -5 to +20 / -45 to +45 |
Screen Rotate [°] | 0 to 90 (landscape to portrait mode) |
Bezel Width [mm] | 16.4 (left and right); 16.8 (top and bottom) |
Dimensions (W x H x D) [mm] | 544.3 x 374.5 x 213.9; Without stand: 544.3 x 322.2 x 53.3 |
Weight [kg] | 5.7 |
VESA Mounting [mm] | 100 x 100 |
Special Characteristics | ErgoDesign®: Height adjustable stand (110 mm), swivel (20°), and portrait (90°) |
Colour Versions | Black Front Bezel, Black Back Cabinet; White Front Bezel, White Back Cabinet |
Cable Management | yes |
Kensington security slot | yes |
Plug and Play | VESA DDC2Bi |
Audio | Integrated Speakers (1 W + 1 W) |
Adjust Functions | Auto Adjust; Auto Brightness; Brightness; Colour Control System; Contrast; Cost Meter; DV Mode; EcoMode; Expansion Mode; Factory Preset; IPM-Setting; Language Select; LED Brightness; Position; Power-Off Timer |
Shipping Content | Monitor; Power Cable; Setup Guide Signal Cable: VGA – VGA |
Safety and Ergonomics | CE; EnergyStar 6.0; ErP; FCC Class B; Flicker-free; ISO 9241-307 (pixel failure class I); Low Blue Light; PCT/Gost; TCO 7.0; TÜV Ergonomics; TÜV GS; UL/C-UL or CSA |
Warranty | 3 years warranty incl. backlight |
Energy Efficiency | Annual energy consumption: 43 kWh (based on 4 operating hours per day); Energy efficiency class: A+ |
Ecological Standards | Energy Star 7.0; TCO 7.0 |
