QNAP TS-1273AU-RP-8G 12-Bay NAS Enclosure

QAR 15,161

Availability:

Available on backorder

Delivery within 3 - 4 weeks.( Delivery time may change depending on the stock)
  • 12 x 3.5″ / 2.5″ SATA III Drive Bays
  • 2.2 GHz AMD V1500B Quad-Core CPU
  • 8GB DDR4 RAM
  • 2 x 2.5G Ethernet Ports
  • 2 x PCIe 3.0 Expansion Slots
  • 1 x USB 3.2 Gen 1 | 3 x USB 3.2 Gen 2
  • RAID 0, 1, 5, 6, 10, 50, and 60
  • 2 RU Rackmount
  • RAID 0, 1, 5, 6, 10, 50, 60 & JBOD
  • QTS 4.4.2 Operating System
  • 12 x 3.5″ / 2.5″ SATA III Drive Bays
  • 2.2 GHz AMD V1500B Quad-Core CPU
  • 8GB DDR4 RAM
  • 2 x 2.5G Ethernet Ports
  • 2 x PCIe 3.0 Expansion Slots
  • 1 x USB 3.2 Gen 1 | 3 x USB 3.2 Gen 2
  • RAID 0, 1, 5, 6, 10, 50, and 60
  • 2 RU Rackmount
  • RAID 0, 1, 5, 6, 10, 50, 60 & JBOD
  • QTS 4.4.2 Operating System

QAR 15,161

Available on backorder

Order By Call

Order now & Get it delivered Today!!

CPU 2.2 GHz Quad-Core
Processor AMD Ryzen V1500B
Total Installed Memory 8 GB DDR4
User-Replaceable Memory 1 x 8 GB
Total Memory Slots 2 x DIMM
Maximum Memory Capacity 64 GB
General
Number of Bays 12 x 2.5″/3.5″
I/O 2 x RJ45 (2.5GbE)
1 x USB Type-A (USB 3.1 / USB 3.2 Gen 1 (5 Gb/s))
2 x USB Type-C (USB 3.1 / USB 3.2 Gen 2 (10 Gb/s))
1 x USB Type-A (USB 3.1 / USB 3.2 Gen 2 (10 Gb/s))
Compatible Drive Interface SATA II, SATA III
Media Card Slots None
Form Factor Rackmount (2 RU)
RAID RAID 0, 1, 10, 5, 50, 6, 60, JBOD, Single
Hot-Swap Support Yes
PCI Expansion 2 x PCIe 3.0 (x4 Electrical)
Wake on LAN Yes
Link Aggregation and Failover Support Yes
Networking
Supported Protocols AFP
CIFS/SMB
FTP
FXP
HTTP
HTTPS
IPv4
IPv6
NFS
Rsync
SFTP
SMB
SMTP
SNMP
SSH
SSL
TFTP
Telnet
WebDAV
iSCSI
iSCSI LUN 256
iSCSI Target 256
Max Cameras Supported 8
Software
Installed Operating System QTS 4.4.2
Supported File Systems Internal: EXT4
External: EXT3, EXT4, FAT32, HFS+, NTFS, exFAT
OS Compatibility macOS 10.10 or Later
Windows 7 or Later
Windows Server 2008 R2 or Later
UNIX
Linux
Ubuntu 14.4
CentOS 7
*As of March, 2021: check with manufacturer for the most up-to-date compatibility
Supported Browsers Chrome, Edge, Firefox, Internet Explorer, Safari
Security
Encryption 256-Bit AES, FIPS 140-2 Level 2
Security Features None
VPN Server Connections 100
Electrical
AC Input Power 100 to 240 VAC, 50 / 60 Hz
Power Source AC Adapter
Power Consumption 78.92 W (Typical)
43.67 W (Idle)
PSU Wattage 2 x 300 W
Environmental
Operating Temperature 32 to 104°F / 0 to 40°C
Operating Humidity 5 to 95%
Storage Temperature -4 to 158°F / -20 to 70°C
Physical
Status Monitoring LED Indicator
Audible Alarm Yes
Cooling 2 x 80 mm Fans
Noise Level 22.3 to 45.9 dBA
Built-In Speakers None
IR Sensor None

Expand your network storage capacity to support backups, VLANs, file sharing and more with the QNAP TS-1273AU-RP-8G 12-Bay NAS Enclosure. This high-performance 2 RU rackmount network storage device includes 12 bays, supporting 3.5″ or 2.5″ SATA III drives that can be configured in RAID 0, 1, 5, 6, 10, 50, 60, JBOD, or Single mode. Its dual 2.5G Ethernet ports deliver reliable file transfers with compatible devices, and they can be combined for 5 Gb/s speed using link aggregation. The TS-1273AU-RP-8G can achieve sequential read and write speeds of up to 542 MB/s and 591 MB/s respectively using solid-state drives in RAID 5 configuration and both Ethernet ports. This NAS also features a 2.2 GHz AMD V1500B quad-core processor with 8GB of memory to boost virtual machine performance. You can further customize performance by installing upgrade cards such as an entry-level graphics card, 10G Ethernet adapter, and M.2 SSD cache expansions into the two available PCIe 3.0 slots. The TS-1273AU-RP-8G has the QTS 4.4.2 operating system pre-installed and is compatible with Windows, Mac, Linux, and Unix systems.

General Features

High-Performance NAS
The 2.2 GHz AMD V1500B quad-core processor with 8GB of memory help to boost virtual machine performance.

Network Storage
Twelve 3.5″ SATA III 6 Gb/s drive bays are available. Installed drives can be set to RAID 0, 1, 5, 6, 10, 50, 60, JBOD, or Single configuration. Backup your business’s data, share files across your network, and streamline multi-user media workflows.

Dual 2.5GbE Network Connections
The QNAP TS-1273AU-RP-8G includes two 2.5GbE RJ45 LAN ports that can help accelerate file sharing, virtual machine applications, or multimedia transmission. Up to 5 Gb/s speeds can be achieved using link aggregation.

PCIe Expansion Slots
The two PCIe Gen 3 slots allow you add expansions such as an entry level graphics card for hardware-accelerated video transcoding, 10G network adapters, and M.2 SSD cache storage adapters.

USB Ports
A 5 Gb/s USB 3.2 Gen 1 Type-A port is available alongside a 10 Gb/s USB 3.2 Gen 2 Type-C port and two Type-A ports.

Cooling
Three quiet-operating 80mm fans help to maintain optimal temperatures.

Powered Up
The TS-1273AU-RP-8G includes two 300W power supplies.
