QNAP TS-233-US 2-Bay NAS Enclosure

QAR 1,237


Available on backorder

Delivery within 3 - 4 weeks.( Delivery time may change depending on the stock)
  • 2 x 3.5″ / 2.5″ SATA III Drive Bays
  • 2 GHz ARM Cortex-A55 Quad-Core CPU
  • 2GB RAM
  • 1 x Gigabit Ethernet Port
  • 1 x USB 3.1 Gen 1 | 2 x USB 2.0
  • AES 256-Bit Volume Encryption
  • QTS 5.0.0 Operating System
  • 2 x 3.5″ / 2.5″ SATA III Drive Bays
  • 2 GHz ARM Cortex-A55 Quad-Core CPU
  • 2GB RAM
  • 1 x Gigabit Ethernet Port
  • 1 x USB 3.1 Gen 1 | 2 x USB 2.0
  • AES 256-Bit Volume Encryption
  • QTS 5.0.0 Operating System

QAR 1,237

Available on backorder

Order By Call

Order now & Get it delivered Today!!

CPU 2 GHz Cortex A55 Quad-Core
Total Installed Memory 2 GB
Maximum Memory Capacity 2 GB
Flash Memory 4 GB
Number of Bays 2 x 2.5″/3.5″
I/O 1 x RJ45 (Gigabit Ethernet)
2 x USB Type-A (USB 2.0 (480 Mb/s))
1 x USB Type-A (USB 3.1 / USB 3.2 Gen 1 (5 Gb/s))
Compatible Drive Interface SATA II, SATA III
Media Card Slots None
Form Factor Desktop
RAID RAID 0, 1, JBOD, Single
Wake on LAN Yes
Supported Protocols AFP
iSCSI Target 256
Max Concurrent Connections 200
Max Folders 512
Max Sync Tasks 400
Max Groups 512
Max User Accounts 4096
Max Volume Number 128
Installed Operating System QTS 5.0.0
Supported File Systems Internal: EXT4
External: EXT3, EXT4, FAT32, HFS+, NTFS, exFAT
OS Compatibility macOS 10.10 or Later
Windows 7 or Later
Windows Server 2008 R2 or Later
Ubuntu 14.4 or Later
CentOS 7 or Later
*As of March, 2022: check with manufacturer for the most up-to-date compatibility
Supported Browsers Chrome, Edge, Firefox, Safari
Encryption 256-Bit AES
Security Features None
AC Input Power 100 to 240 VAC, 50 / 60 Hz
Power Source AC Adapter
Power Consumption 10.81 W (Typical)
3.43 W (Standby)
PSU Wattage 1 x 65 W
Operating Temperature 32 to 104°F / 0 to 40°C
Operating Humidity 5 to 95%
Storage Temperature -4 to 158°F / -20 to 70°C
Status Monitoring LED Indicator
Audible Alarm Yes
Cooling 1 x 80 mm Fan
Built-In Speakers None
IR Sensor None
Dimensions 7.43 x 6.15 x 3.55″ / 18.87 x 15.62 x 9.02 cm
Weight 2.5 lb / 1.1 kg

Add convenience and peace of mind to your home or small office with the QNAP TS-233-US 2-Bay NAS Enclosure providing external storage to back up your important files, photos, and other media. Featuring a stylish, low-profile design, this entry-level NAS is built to blend in with most environments while delivering optimal airflow to its internal components. You can install two separately sold 3.5″ / 2.5″ SATA III drives into its bays and connect the enclosure to your network through its Gigabit Ethernet port, allowing you to use Apple Time Machine and NetBak for Windows to automatically back up your computer in the background. Mobile device and Google Drive cloud storage backups are also supported, so you can rest easy knowing that your data is secure. Additionally, you can place this NAS at the heart of your entertainment experience by streaming videos, photos, and music to network connected devices. The TS-233 uses the QTS 5.0.0 operating system.

Powered by a 2 GHz ARM Cortex-A55 quad-core processor and 2GB of memory, the TS-233 features 114 MB/s read and 103 MB/s write speeds in RAID 1 configuration.

NPU AI Acceleration
A built-in Neural network Processing Unit (NPU) drives the TS-233’s artificial intelligence engine, which helps to deliver enhanced facial and object recognition when using the QuMagie photo management app.

Hybrid Backup Sync
Hybrid Backup Sync supports all your favorite public cloud services, allowing you to effortlessly back up or sync NAS files to cloud storage.

USB Connectivity
Transfer files directly to the NAS by connecting flash drives and other compatible storage devices to the two USB 2.0 and one 5 Gb/s USB 3.1 Gen 1 Type-A ports. You can also enhance your network transfer speeds by using a 5GbE USB Ethernet adapter.

Enhanced Multimedia Streaming
The TS-233 supports ARM NEON technology to accelerate video processing for a greater entertainment experience. Stream media files from the NAS to DLNA devices and TVs using media streaming devices such as Roku, Apple TV (via Qmedia), Google Chromecast, and Amazon Fire TV.

High Security
Hardware-based AES 256-bit encryption works alongside features such as 2-step verification, advanced folder permissions, a firewall, VPN access, and an integrated security counselor to protect your data.

Remote Access
The myQNAPcloud service enables quick and easy remote access to your TS-233, allowing you to always be connected without needing to configure complex network settings. With myQNAPcloud Link you are provided with a unique domain name for your TS-233, and will automatically connect using the best method based on your network environment.
