QNAP TVS-h1288X 16G 12-Bay NAS Enclosure

QAR 18,233

Availability:

Available on backorder

Delivery within 3 - 4 weeks.( Delivery time may change depending on the stock)
SKU: TVS-h1288X-W1250-16G

Categories: , ,

  • 8 x 3.5″ / 4 x 2.5″ SATA III Drive Bays
  • 2 x M.2 2280 / 22110 SSD Cache Slots
  • 3.3 GHz Intel Xeon W-1250 Six-Core CPU
  • 16GB ECC DDR4 RAM
  • 3 x 2.5G / 2 x 10G Ethernet Ports
  • USB 3.2 Gen 2 Type-A & Type-C Ports
  • 3 x PCIe 3.0 Expansion Slots
  • RAID 0, 1, 5, 6, 10, 50, 60 + Hot Spare
  • Up to 4646 MB/s Read Speed
  • QuTS Hero 4.5.0 Operating System
  • 8 x 3.5″ / 4 x 2.5″ SATA III Drive Bays
  • 2 x M.2 2280 / 22110 SSD Cache Slots
  • 3.3 GHz Intel Xeon W-1250 Six-Core CPU
  • 16GB ECC DDR4 RAM
  • 3 x 2.5G / 2 x 10G Ethernet Ports
  • USB 3.2 Gen 2 Type-A & Type-C Ports
  • 3 x PCIe 3.0 Expansion Slots
  • RAID 0, 1, 5, 6, 10, 50, 60 + Hot Spare
  • Up to 4646 MB/s Read Speed
  • QuTS Hero 4.5.0 Operating System

QAR 18,233

Available on backorder

Order By Call

Order now & Get it delivered Today!!

CPU 3.3 to 4.7 GHz 6-Core
Processor Intel Xeon W-1250
GPU Intel UHD Graphics P630
Total Installed Memory 16 GB ECC DDR4
User-Replaceable Memory 2 x 8 GB
Total Memory Slots 4 x DIMM
Maximum Memory Capacity 128 GB
General
Number of Bays 8 x 2.5″/3.5″
4 x 2.5″
2 x M.2 (22110)
I/O 2 x RJ45 (10GbE)
4 x RJ45 (2.5GbE)
2 x USB Type-C (USB 3.1 / USB 3.2 Gen 2 (10 Gb/s))
3 x USB Type-A (USB 3.1 / USB 3.2 Gen 2 (10 Gb/s))
1 x HDMI Type-A (HDMI 1.4b)
Compatible Drive Interface SATA II, SATA III
Media Card Slots None
Form Factor Desktop
RAID RAID 0, 1, 10, 5, 50, 6, 60, JBOD
Hot-Swap Support Yes
PCI Expansion 1 x PCIe 3.0 (x8 Electrical)
2 x PCIe 3.0 (x4 Electrical)
Wake on LAN Yes
Link Aggregation and Failover Support Yes
Networking
Supported Protocols AFP
CIFS/SMB
FTP
HTTP
HTTPS
IPv4
IPv6
L2TP/IPSec
MPIO
NFS
OpenVPN
PPTP
Proxy
Rsync
SAN
SFTP
SMSC
SMTP
SNMP
SSH
SSL
Syslog
TFTP
Telnet
WebDAV
iSCSI
iSCSI LUN 256
iSCSI Target 256
Max Groups 200,000
Software
Installed Operating System QTS 4.5.0
OS Compatibility Windows 7 or Later
Windows Server 2008 R2 or Later
macOS 10.10 or Later
Ubuntu 14.4 or Later
CentOS 7
Linux
UNIX
*As of February, 2021: check with manufacturer for the most up-to-date compatibility
Supported Browsers Chrome, Firefox, Internet Explorer, Safari
Security
Encryption 256-Bit AES, FIPS 140-2 Level 2
Security Features Kensington Security Slot
VPN Client Connections 100
Electrical
AC Input Power 100 to 240 VAC, 50 / 60 Hz
Power Source AC Adapter
Power Consumption 97.492 W (Typical)
85.216 W (Idle)
PSU Wattage 1 x 550 W
Environmental
Operating Temperature 32 to 104°F / 0 to 40°C
Operating Humidity 5 to 95%
Storage Temperature -4 to 158°F / -20 to 70°C
Physical
Status Monitoring LCD Screen
Audible Alarm Yes
Cooling 3 x 80 mm Fan
2 x 97 mm Fan
Noise Level 26 dBA
Built-In Speakers None
IR Sensor None
Dimensions 14.56 x 12.59 x 9.24″ / 369.82 x 319.79 x 234.7 mm
Weight 24.9 lb / 11.3 kg

Expand your business’s network storage capacity with the exceptionally versatile TVS-h1288X 12-Bay NAS Enclosure from QNAP. Powered by the QuTS Hero operating system and a 3.3 GHz Intel Xeon W-1250 six-core processor with 16GB ECC DDR4 memory, the TVS-h1288X is designed to reliably and securely transfer and share data across your network to streamline workflows and collaboration. The enclosure includes eight 3.5″ and four 2.5″ hot-swappable SATA III drive bays, and installed drives can be configured in RAID 0, 1, 5, 6, 10, 50, and 60 mode with a hot spare drive. Performance can be further enhanced by installing up to two M.2 2280 or 22110 solid-state cache drives. The TVS-h1288X connects to networks through four 2.5G and two 10G Ethernet ports to optimize the speed and efficiency.

Upgrades such as 25G network adapters and Thunderbolt 3 cards can be installed into the available PCIe 3.0 slots. Other features include 10 Gb/s USB 3.2 Gen 2 Type-A and Type-C ports alongside an HDMI 1.4b output for connecting compatible peripherals. Your data is secured with integrated AES-NI encryption. The TVS-h1288X supports multiple QNAP SATA III and USB Type-C expansion enclosure models for greater capacity.

Fast NAS Performance
The TVS-h1288X can reach up to 4646 MB/s sequential download and 3651 MB/s sequential upload speeds with eight 6TB hard drives in RAID 5 mode and two 2TB cache SSDS over four 10GbE connections.

4K Media Playback
With 4K media playback and real-time transcoding, you can output videos directly to 4096 x 2160 resolution, 30 Hz monitors through the HDMI 1.4b port.

Versatile Storage
With its 3.3 GHz Intel Xeon W-1250 six-core processor and 16GB of ECC DDR4 memory, you can use the TVS-h1288X NAS for data backups, sharing, configuring virtual machines, and more.

QuTS Hero
The QuTS Hero operating system supports a wide variety of features such as self-healing data integerity, enhanced storage efficiency, antiwear leveling to expand the lifespan of drives, and more to enhance storage performance.

Real-time SnapSync Support
With the real-time SnapSync feature, both the primary and secondary NAS maintain identical data. If the primary NAS goes offline, IT administrators can adjust the settings of the secondary NAS to help ensure minimal interruptions to operations.

SKU: TVS-h1288X-W1250-16G Categories: , ,
