Seagate 12TB Exos X16 7200 rpm SATA III 3.5″ Internal HDD

Availability:

Out of stock


  • 12TB Storage Capacity
  • 3.5″ Form Factor
  • SATA III 6 Gb/s Interface
  • 256MB Cache
  • 7200 rpm
  • Data Transfer Speeds up to 245 MB/s
  • 2,500,000 Hours MTBF
  • 8760 Power-On Hours per Year
  • 0.35% Annualized Failure Rate (AFR)
  • 12TB Storage Capacity
  • 3.5″ Form Factor
  • SATA III 6 Gb/s Interface
  • 256MB Cache
  • 7200 rpm
  • Data Transfer Speeds up to 245 MB/s
  • 2,500,000 Hours MTBF
  • 8760 Power-On Hours per Year
  • 0.35% Annualized Failure Rate (AFR)

Out of stock

Order now & Get it delivered Today!!

Storage Capacity Total: 12 TB SATA III (6 Gb/s) 3.5″ HDD (7200 rpm)
Read Speed Maximum: 245 MB/s
Random: 170 IOPS 4 kB Files
Sequential: 233 MB/s
Write Speed Random: 440 IOPS 4 kB Files
Buffer 256 MB
Latency 4.1 ms
HDD Specs
Heads 16
Platters 9
Areal Density 1028 Gb/in²
Disk Sector Format 512e
Noise Level 3.2 dB (Active)
2.8 dB (Idle)
Reliability / Data Integrity
Annualized Failure Rate (AFR) 0.35 %
Encryption None
Endurance (Total Bytes Written) 550 TB
Load/Unload Cycles 600,000
Mean Time Between Failures (MTBF) 2.5 Million Hours
Non-Recoverable Read Errors per Bits Read 1 in 1015
Electrical
Power Draw 5.0 W (Idle)
9.5 W (Active)
6.0 W (Active)
Supported Voltage 5 VDC, 12 VDC
Current 2.6 A at 12 VDC
Environmental
Operating Temperature 41 to 140°F / 5 to 60°C
Storage Temperature -40 to 158°F / -40 to 70°C
Operating Shock 50 G / 2.0 ms
Storage Shock 200 G / 2.0 ms
Operating Vibration 0.7 G / 5 to 500 Hz
Storage Vibration 2.27 G / 2 to 500 Hz
Operating Humidity 5 to 95%
Storage Humidity 5 to 95%
Operating Altitude -1,000 to 10,000′ / -304.8 to 3048 m
Storage Altitude -1,000 to 40,000′ / -304.8 to 12,192 m
General
Dimensions 5.78 x 4.01 x 1.02″ / 146.81 x 101.85 x 25.91 mm
Weight 1.48 lb / 0.67 kg

The 12TB Exos X16 7200 rpm SATA III 3.5″ Internal HDD from Seagate is a high performance, large capacity drive designed for data storage. It’s suitable for engineering workstations, network servers, mainframes, supercomputers, and other demanding tasks that require 24/7 operation. This 7200 rpm drive utilizes the SATA III 6 Gb/s interface for data transfer rates of up to 245 MB/s. Moreover, as a professional-grade drive, it has a MTBF rating of 2.5 million hours as well as built-in digital sensors to ensure optimal performance.

Maximum Storage Capacity for Highest Rack Space Efficiency

  • Hyperscale model tuned for large data transfers
  • PowerBalance feature optimizes IOPS/Watt
  • Built-in digital environmental sensors for measuring internal humidity, pressure, and temperature to ensure reliability, performance, and quality
  • 2.5 million hours MTBF

Best-Fit Applications

  • Hyperscale applications/cloud data centers with replicated storage
  • Massive scale-out data centers and big data analytics
  • OLTP and HPC applications
  • High-capacity density RAID storage
  • Mainstream enterprise external storage arrays (SAN, NAS, DAS)
  • Distributed file systems, including Hadoop and Ceph
  • Enterprise backup and restore – D2D, virtual tape
  • Centralized surveillance
