|Plug Type||EU, UK, US|
|Interface||1 * 10/100M Ethernet Port (RJ45)|
|Button||RE (Range Extender) Button, Reset Button|
|Power Consumption||About 3W|
|Wireless Standards||IEEE 802.11n, IEEE 802.11g, IEEE 802.11b|
|Dimensions ( W x D x H )||4.3x 2.6 x 3.0in. (110.0 x 65.8 x 75.2mm)|
|Antenna||2 * internal|
|Signal Rate||11n: Up to 300Mbps (dynamic)
11g: Up to 54Mbps (dynamic)
11b: Up to 11Mbps (dynamic)
|Reception Sensitivity||270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
|Transmit Power||< 20 dBm (EIRP)|
|Wireless Modes||Range Extender/Access Point|
|Wireless Functions||WMM (Wi-Fi Multimedia)
Wireless MAC Address Filtering
Domain Login Function
|Wireless Security||64/128/152-bit WEP
WPA-PSK / WPA2-PSK
|Package Contents||300Mbps Universal Wi-Fi Range Extender TL-WA850RE
RJ-45 Ethernet Cable
Quick Installation Guide
|System Requirements||Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux.|
|Environment||Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Boost Your Wireless Network
Tired of Wi-Fi ’’dead zone’’? TP-Link’s range extender connects to your router wirelessly, strengthening and expanding its signal into areas it can’t on its own. The device also reduces signal interference to ensure reliable Wi-Fi coverage throughout your home or office.
Easy Setup and Flexible Placement
Press the WPS button on your router and the Range Extender button on your 850RE within 2 minutes to easily connect to the network. Once connected with an existing router, you can simply unplug and plug the TL-WA850RE back in a location for the best signal quality and coverage in your house, without needing to configure the extender again.
The TL-WA850RE’s single Ethernet port allows the Extender to function as a wireless adapter to connect wired devices like Blu-ray® players, gaming consoles, DVRs and Internet TVs. At the same time, the device can share the wireless network as well.
Smart Signal Indicator Light
5 signal lights show the strength of signal that TL-WA850RE receives from the existing router, which can help to find the right location to place the range extender. It’s recommended that you choose a location where at least 3 signal light blue in order to guarantee a good performance.
Tether App for Easy Use
Use any mobile device to easily access and manage various features, including the LED Control function’s Night Mode, which allows you to enjoy a more peaceful night’s sleep.
