Tripp Lite Cat6 Gigabit Molded (UTP) Ethernet Cable (RJ45 M/M), Blue, 5 ft. (1.52 m)

QAR 19

Availability:

In stock


  • Premium cabling for Cat5/5e/6 home/office network applications
  • Rated for 550 MHz/1 Gbps communication
  • 24 AWG 4-pair stranded UTP with PVC jacket
  • Gold-plated copper contacts minimize data loss
  • Integral strain relief protects connectors from stress and cracking
  • Premium cabling for Cat5/5e/6 home/office network applications
  • Rated for 550 MHz/1 Gbps communication
  • 24 AWG 4-pair stranded UTP with PVC jacket
  • Gold-plated copper contacts minimize data loss
  • Integral strain relief protects connectors from stress and cracking

QAR 19

In stock

Order By Call

Order now & Get it delivered Today!!

PHYSICAL

Cable Jacket Color Blue
Cable Jacket Material PVC
Cable Jacket Rating CM
Cable Shielding UTP
Cable Outer Diameter (OD) 6.0mm
Number of Conductors 4 Pair
Conductor Material Stranded Copper
Conductor Gauge 24 AWG
Cable Length (ft.) 5
Cable Length (in.) 60
Shipping Dimensions (hwd / in.) 7.00 x 9.00 x 0.50
Shipping Weight (lbs.) 0.16

ENVIRONMENTAL

Operating Temperature Range 14 to 104 F (-10 to 40 C)
Storage Temperature Range 5 to 122 F (-15 to 50 C)
Operating Humidity Range 0% to 90% RH, Non-Condensing
Storage Humidity Range 0% to 90% RH, Non-Condensing

COMMUNICATIONS

Bandwidth per TIA Standard 250 MHz
Maximum Bandwidth as Tested 500 MHz
Network Compatibility 1 Gbps (Gigabit)
IEEE Standards Supported 802.3an

CONNECTIONS

Side A – Connector 1 RJ45 (MALE)
Side B – Connector 1 RJ45 (MALE)
Crossover Wiring No
Contact Plating Gold
Connector Type Molded
Wiring Configuration EIA/TIA 568B

FEATURES & SPECIFICATIONS

IP68 Rated No
Snagless Connector No

STANDARDS & COMPLIANCE

Product Compliance RoHS; IEEE 802.3an 10GBase-T; REACH

The Ideal Solution for All High-Speed Cat5/5e/6 Networking

  • Connects high-speed network components, such as computers, printers, video game systems, Blu-ray players, copy machines, routers and modems
  • Designed for 1000Base-T, 10/100Base-T (Ethernet), 100 Mbps TPDDI, 155 Mbps ATM, ISDN, voice, Token Ring Type 3 and EIA/TIA applications
  • Recommended for home or office applications
  • Provides high-speed connections up to 550 MHz/1 Gbps
  • Flawless signal delivery with minimal near-end crosstalk levels

Premium Construction Ensures Error-Free Signal Transfer

  • Manufactured from 24 AWG 4-pair stranded UTP with staggered-pin plug design
  • Molded RJ45 connectors and gold-plated copper contacts for maximum conductivity and minimum data loss
  • Integral strain relief protects cable and connectors from stress and cracking
  • Meets most current industry standards, including IEEE 802.3ab, IEEE 802.5, ANSI/EIA/TIA 568, ISO/IEC 11801 and ETL (category 6 draft 11)
