Teltonika FMC130 – 4G LTE Bluetooth Advanced GPS Tracker

QAR 699

Availability:

Out of stock

SKU: FMC130C5B101

Categories: , , , ,

  • Newly introduced FMC130 is a small ADVANCED series device with 4G (LTE Cat 1) network coverage including 3G (UMTS), 2G (GSM) fallback compatibility.
  • FMC130 developed on the existing Teltonika FMB platform
  • For starters, FMC130 features negative input which allows you to save precious integration time while connecting accessories
  • Additionally, the device has an integrated possibility to enable Impulse Input for precise fuel flow meter data reading.
  • Programmable inputs, 3 different configurable DOUT scenarios
  • Newly introduced FMC130 is a small ADVANCED series device with 4G (LTE Cat 1) network coverage including 3G (UMTS), 2G (GSM) fallback compatibility.
  • FMC130 developed on the existing Teltonika FMB platform
  • For starters, FMC130 features negative input which allows you to save precious integration time while connecting accessories
  • Additionally, the device has an integrated possibility to enable Impulse Input for precise fuel flow meter data reading.
  • Programmable inputs, 3 different configurable DOUT scenarios

QAR 699

Out of stock

Order now & Get it delivered Tomorrow!!

MODULE
Name MeiG SLM320-E, MeiG SLM320-LA, Quectel EC21-AU, Quectel EC21-EC, Quectel EC21-KL, Quectel EC21-J, Teltonika TM2500
Technology LTE(CaT1)/3G(UMTS/HSPA)/2G(GSM/GPRS)/GNSS/BLUETOOTH
GNSS
GNSS GPS, GLONASS, GALILEO, BEIDOU, QZSS, AGPS
Receiver Tracking: 33
Tracking sensitivity -165 dBM
Accuracy < 2.5m CEP
Velocity Accuracy < 0.1 m/s (within +/- 15% error)
Hot start < 1 s
Warm start < 25 s
Cold start < 35 s
Technology LTE Cat 1, UMTS, GSM
2G bands (EC21) EC21-AU:GSM: B2/B3/B5/B8
EC21-EC:GSM: B3/B8
2G bands (SLM320) FMC130-ME1:GSM: B2/B3/B5/B8
FMC130-ME3:GSM: B2/B3/B5/B8
FMC130-ML1:GSM: B2/B3/B5/B8
3G bands (EC21) EC21-AU:WCDMA: B1/B2/B5/B8
EC21-EC:WCDMA: B1/B8
4G bands (EC21) EC21-AU: LTE FDD: B1/B2/B3/B4/B5/B7/B8/B28 LTE TDD: B40
EC21-EC: LTE FDD: B1/B3/B7/B8/B20/B28A
EC21-KL: LTE FDD: B1/B3/B5/B7/B8
EC21-J: LTE FDD: B1/B3/B8/B18/B19/B26
4G bands (SLM320) FMC130-ME1: LTE FDD: B1/B3/B5/B7/B8/B20 LTE-TDD:B38/B40/B41
FMC130-ME3: LTE FDD: B1/B3/B7/B8/B20/B28 LTE-TDD:B38/B40/B41
FMC130-ML1: LTE FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28 LTE-TDD:B40
Data transfer (EC21) LTE:LTE FDD: Max 10Mbps (DL)/Max 5Mbps (UL)
LTE TDD: Max 8.96Mbps (DL)/Max 3.1Mbps (UL)
UMTS:WCDMA: Max 384Kbps (DL)/Max 384Kbps (UL)
GSM:GPRS: Max 107Kbps (DL)/Max 85.6Kbps (UL)
Data transfer (SLM320) LTE:LTE FDD: Max 10Mbps (DL)/Max 5Mbps (UL)
LTE TDD: Max 8Mbps (DL)/Max 2Mbps (UL)
GSM:GPRS: Max 85.6Kbps (DL)/Max 85.6Kbps (UL)
Data support SMS (text/data)
POWER
Input voltage range 10 – 30 V DC with overvoltage protection
Internal Back-up battery 170 mAh Li-Ion, 3.7 V battery (0.63 Wh)
Internal fuse 3A, 125V
Power consumption At 12V < 3 mA (Ultra Deep Sleep)
At 12V < 5 mA (Deep Sleep)
At 12V < 16 mA (Online Deep Sleep)
At 12V < 18 mA (GPS Sleep)
At 12V < 33 mA (nominal with no load)
At 12V < 2A Max. (with full Load / Peak)
BLUETOOTH
Specification 4.0 + LE
Supported peripherals Temperature and Humidity sensor, OBDII dongle, Inateck Barcode Scanner, Universal BLE sensors support
PHYSICAL SPECIFICATION
Dimensions 65 x 56,6 x 20,6 mm (L x W x H)
Weight 55 g
OPERATING ENVIRONMENT
Operating temperature (without battery) -20 °C to +85 °C
Storage temperature (without battery) -20 °C to +85 °C
Operating temperature (with battery) -20 °C to +40 °C
Storage temperature (with battery) -20 °C to +45 °C
Operating humidity 5% to 95% non-condensing
Ingress Protection Rating IP41
Battery charge temperature 0 °C to +45 °C
Battery discharge temperature -20 °C to +60 °C
Battery storage temperature -20 °C to +45 °C for 1 month
-20 °C to +35 °C for 6 months
INTERFACE
Digital Inputs 3
Negative Inputs 1 (Digital Input 2)
Impulse Inputs 2 (Digital Input 1, Digital Input 2)
Digital Outputs 3
Analog Inputs 2
CAN Adapter inputs 1
1-Wire 1
GNSS antenna Internal High Gain
Cellular antenna Internal High Gain
USB 2.0 Micro-USB
LED indication 2 status LED lights
SIM Micro-SIM + eSIM
Memory 128MB internal flash memory
FEATURES
Sensors Accelerometer
Scenarios Green Driving, Over Speeding detection, GNSS Fuel Counter, DOUT Control Via Call, Excessive Idling detection, Immobilizer, iButton Read Notification, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip
Sleep modes GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep
Configuration and firmware update FOTA Web, FOTA, Teltonika Configurator (USB, Bluetooth), FMBT mobile application (Configuration)
SMS Configuration, Events, DOUT control, Debug
GPRS commands Configuration, DOUT control, Debug
Time Synchronization GNSS, NITZ, NTP
Fuel monitoring LLS (Analog), LV-CAN200, ALL-CAN300, CAN-CONTROL, OBDII dongle
Ignition detection Digital Input 1, Accelerometer, External Power Voltage, Engine RPM (CAN Adapters, OBDII dongle)

Newly introduced FMC130 is a small ADVANCED series device with 4G (LTE Cat 1) network coverage including 3G (UMTS), 2G (GSM) fallback compatibility. It comes equipped with internal GNSS, LTE antennas, configurable digital/analog/negative and impulse inputs, three DOUT outputs, Bluetooth connectivity, and backup battery.

FMC130 developed on the existing Teltonika FMB platform, therefore it keeps all of the functionalities from FMB130 and builds on top of them with its industry-leading connectivity coverage.

For starters, FMC130 features negative input which allows you to save precious integration time while connecting accessories like vehicle doors sensor, alarm buttons, seatbelt detection, and other similar sensors or accessories.

Additionally, the device has an integrated possibility to enable Impulse Input for precise fuel flow meter data reading. Impulse based fuel usage monitoring is much more accurate than a different type of fuel metering sensors and it makes the FMC130 a perfect solution for high fuel usage machines like cranes, construction vehicles, mining machines, agriculture equipment.

Programmable inputs, 3 different configurable DOUT scenarios (immobilizer, buzzer, alarm lights, door lock and other scenarios) together with 4G (LTE Cat 1) compatibility including the 3G (UMTS) and 2G (GSM) fallback compatibility make this one of our most flexible devices ever.
